What is a Decarbonization annealing heat treatment furnace? Introduction to the Working Principle of heating furnace

Decarbonization annealing heat treatment furnaceIt is a kind of equipment that uses natural gas as fuel to heat metal materials and make them reach forging temperature.，it is usually composed of convection chamber, ventilation system, recovery of waste heat, Radiation chamber and furnace chamber，This productSimple structure and reliable operation.，usually used in heat treatment, electron, material, petroleum, pharmacy and other fields。The following is to introduce the Decarbonization annealing heat treatment furnace:

1、Brief introduction of Decarbonization annealing heat treatment furnace

Decarbonization annealing heat treatment furnaceIt is a kind of equipment which uses gas as fuel and is specially used for heating metal before forging.，the advantage is The use of clean and environmentally friendly natural gas as fuel effectively avoids the adverse effects of chemical reactions between impurities such as coal-fired furnaces and forgings during heating. At the same time, natural gas has high calorific value and high combustion temperature, and the combustion temperature can be further increased by preheating air and fuel. In addition, the gas forging heating furnace also has good heat loss control ability and intelligent control system, which can accurately adjust the ratio of air to natural gas, ensure full combustion of natural gas, and reduce mechanical incomplete combustion and chemical incomplete combustion.、Using regenerative combustion system or advanced burner design can realize the uniform distribution of temperature in the furnace, ensure the uniform heating of metal materials and improve product quality.、Adopting advanced combustion technology and control system can realize full combustion of natural gas and improve combustion efficiency. At the same time, some equipment is also equipped with waste heat recovery system, which can further recycle the waste heat in exhaust smoke and improve energy utilization efficiency.、It has the advantages of high heating efficiency, high energy utilization, accurate temperature control, good environmental protection performance, simple operation and strong adaptability.、Usually equipped with intelligent control system, it can automatically adjust the parameters such as gas supply and air flow according to the heating demand, and realize accurate control of the temperature and atmosphere in the furnace.。

Decarbonization annealing heat treatment furnace

2、Working principle of Decarbonization annealing heat treatment furnace

Decarbonization annealing heat treatment furnaceat the start of the operation,The high-temperature flame and flue gas generated when the fuel burns in the furnace are used as heat sources to heat the medium flowing in the tube to reach the specified process temperature. Fuel is ejected from the burner and burned, resulting in high-temperature flame and high-temperature flue gas. The high-temperature flame transfers heat to the furnace tube in the radiation chamber through radiation, and then to the medium in the furnace tube. The high-temperature flue gas enters the convection chamber of the heating furnace upward due to the suction force of the chimney or the action of the induced draft fan, and the heat is transferred to the furnace tube in the convection chamber by convection, and then to the medium in the furnace tube.，The overall structural design is relatively simple and compact.，it has the structure of convection chamber, combustor, ventilation system, furnace chamber and combustor，modern technology。

Decarbonization annealing heat treatment furnace

3、Decarbonization annealing heat treatment furnace structure composition

The Decarbonization annealing heat treatment furnace has the following structure

1. Radiation chamber

The heat load of the main place for Decarbonization annealing heat treatment furnace heat exchange accounts for about 70%-80% of the whole furnace. The furnace tube in the radiation room conducts heat through flame or high-temperature flue gas, which is mainly radiant heat, so it is called radiation tube.

2. convection chamber

The material is heated by convection heat transfer of high temperature flue gas discharged from the radiation chamber. Flue gas washes the tube wall of the furnace tube at a high speed to carry out effective convection heat transfer, and its heat load accounts for about 20%-30% of the whole furnace. The convection chamber is generally arranged above the radiation chamber, and some are placed on the ground alone. In order to improve the heat transfer effect, nail head tubes or finned tubes are often used in furnace tubes.

3. combustor

The device that mixes natural gas with combustion-supporting air and ejects it is the core component of the heating furnace.

4. ventilation system

Ensure the gas flow in the furnace and maintain the stability of the atmosphere and temperature in the furnace.

5. Waste heat recovery system

Recover the waste heat in the exhaust gas of heating furnace to improve the energy utilization efficiency.

Decarbonization annealing heat treatment furnace

4、Decarbonization annealing heat treatment furnace use

The purpose of Decarbonization annealing heat treatment furnace is introduced as follows:

1. Energy conservation and environmental protection

The Decarbonization annealing heat treatment furnace uses clean energy as fuel, which has lower emissions and higher energy efficiency than traditional coal-fired or oil-fired stoves. This is helpful to reduce environmental pollution and realize green production.

2. Metal tempering

By properly heating and cooling the metal material, the Decarbonization annealing heat treatment furnace can realize the quenching and tempering treatment of the metal. This is helpful to adjust the hardness and toughness of metal to meet the needs of different workpieces.

3. Improve production efficiency

The Decarbonization annealing heat treatment furnace has the advantages of fast heating speed and accurate temperature control, which can improve production efficiency. This is especially important for mass-produced forging workshops.

4. Metal melting and casting

Although it is mainly used for forging heating, some types of Decarbonization annealing heat treatment furnaces can also be used in metal melting and casting processes. This is especially suitable for melting and casting of small or special alloys.

5. Metal forging heating

The Decarbonization annealing heat treatment furnace can heat the metal material to the temperature required for forging, improve its plasticity and fluidity, and thus facilitate forging. This is very important for the forging of various metal materials.

Decarbonization annealing heat treatment furnace

5、Decarbonization annealing heat treatment furnace characteristics

The Decarbonization annealing heat treatment furnace features are as follows:

1. Efficient heating

The Decarbonization annealing heat treatment furnace can heat the metal to the required forging temperature in a very short time, reducing the loss caused by the oxidation of the metal.

2. Strong adaptability

The Decarbonization annealing heat treatment furnace is suitable for forging and heating of various metal materials and has a wide range of applications.

3. Stable and reliable

The Decarbonization annealing heat treatment furnace has a stable combustion system and temperature control system, which can ensure the uniformity and stability of the temperature in the furnace, thus improving the quality and production efficiency of forged products.

4. Easy to maintain

The structural design of the Decarbonization annealing heat treatment furnace is reasonable and easy to maintain, which reduces the operating cost and failure rate of the equipment.

5. energy saving and environmental protection

As a clean energy source, natural gas produces less pollutants after combustion, which is beneficial to environmental protection. At the same time, the application of waste heat recovery system further improves the energy utilization efficiency.

Decarbonization annealing heat treatment furnace

6、One-combustion energy saving's strength

The company has many years of Decarbonization annealing heat treatment furnace manufacturing experience, large scale and strong strength.。

One-combustion energy saving

Decarbonization annealing heat treatment furnaceat work,The high-temperature flame and flue gas generated by burning gas (such as natural gas and liquefied petroleum gas) in the furnace are used as heat sources to heat metal materials.，multifunctional, with functions such as anneal, temper, Forging heating, normalizing and Casting heating。
